360x640 IPS TFT LCD display with SPI interface(HC030IT30043-B86)

Specification parameters

P/N HC030IT30043-B86
Size 3"(IPS)
Display type IPS
Resolution 360x640
Aspect ratio 9:16
Contrast ratio 800:1
Outline Dimension(mm) 43.04(W)*74.91(H)*2.3(D)mm
Active Area(mm) 36.72(W)*65.28(H)mm
Brightness(cd/m²） 300cd/m2
Viewing Angle(L/R/T/B) 80/80/80/80
Interface 30PIN SPI
Operation Temp -20~70℃
Storge Temp -30~80℃
Application IP phone, Handheld Digital Microscope, Retro Game Console, Smart Faucet, Colorimeter
