3 inch 480x854 resolution IPS TFT LCD module for Industrial (HC030IX50021-N88)

Specification parameters

P/N HC030IX50021-N88
Size 3"(IPS)
Display type IPS
Resolution 480*854
Aspect ratio 9:16
Contrast ratio 800:1
Outline Dimension(mm) 42.9(W)*74.8(H)*2.06(D)mm
Active Area(mm) 36.72(W)*65.28(H)mm
Brightness(cd/m²） 500cd/m2
Viewing Angle(L/R/T/B) 80/80/80/80
Interface 40 PIN RGB/40 PIN MIPI
Operation Temp -20~70℃
Storge Temp -30~80℃
Application IP phone, Battery tester, Transistor Tester, Spectrophotometer.
