8.8 inch long strip lcd screen (HC088IX35060-F97）

Specification parameters

P/N HC088IX35060-F97
Size 8.8"(IPS)
Display type IPS
Resolution 1280*480
Aspect ratio 8:3
Contrast ratio 1000
Outline Dimension(mm) 229.7(W)*97.4(H)*6(D)mm
Active Area(mm) 176.64(W)*99.36(H) mm
Brightness(cd/m²） 350cd/m2
Viewing Angle(L/R/T/B) 85/85/85/85
Interface 40PIN MIPI
Operation Temp -20~70℃
Storge Temp -30~80℃
Application Charging post,Department calling screen,Transportation system
