10.1 inch IPS 1280*800 resolution 40PIN LVDS 800nits LCD for intercom (HC101IP80025-A44）

Specification parameters

P/N HC101IP80025-A44
Size 10.1"(IPS)
Display type IPS
Resolution 1280*800
Aspect ratio 8:5
Contrast ratio 800
Outline Dimension(mm) 229.46(W)*149.1(H)*2.51(D)mm
Active Area(mm) 216.96(W)*135.6(H) mm
Brightness(cd/m²） 800cd/m2
Viewing Angle(L/R/T/B) 85/85/85/85
Interface 40Pin LVDS
Operation Temp -20~70℃
Storge Temp -30~80℃
Application Charging post,Department calling screen,Transportation system
