8 inch hdmi display(HCTG080V.CP1）

Specification parameters

P/N HCTG080V.CP1
Size 8"(TN)
Display type TN
Resolution 800*480
Aspect ratio 16:9
Contrast ratio 500
Outline Dimension(mm) 192.8(W)*116.9(H)*22(D)mm
Active Area(mm) 176.64(W)*99.36(H)mm
Brightness(cd/m²） 500cd/m2
Viewing Angle(L/R/T/B) 70/70/50/70
Interface HDMI+TYPE C
Operation Temp 0~60℃
Storge Temp 0~60℃
Application Charging post,Department calling screen,Transportation system
