12.8 inch IPS 1920x1080 resolution 50PIN LVDS 600nits LCD (HC128IX60065-G17）

Specification parameters

P/N HC128IX60065-G17
Size 12.8"(IPS)
Display type IPS
Resolution 1920*1080
Aspect ratio 16:9
Contrast ratio 1500
Outline Dimension(mm) 294.4(W)*175(H)*6.5(D)mm
Active Area(mm) 283.39(W)*159.4(H) mm
Brightness(cd/m²） 600cd/m2
Viewing Angle(L/R/T/B) 85/85/85/85
Interface 50Pin LVDS
Operation Temp -30~85℃
Storge Temp -40~90℃
Application Charging post,Department calling screen,Transportation system
