5 inch high brightness automobile tft lcd(HC050IGA3070-F22)

Specification parameters

Brand Hetech
P/N HC050IGA3070-F22
Size 5"(IPS)
Display mode IPS,Transmissive,normally black
Resolution 800X480
Aspect ratio 16:9
Outline Dimension(mm) 121(W) ×78.8(H) ×7.00(D)
Active Area(mm) 108(W) ×64.8 (H)
Brightness(cd/m²） 1350cd/㎡
Viewing Angle(L/R/T/B) 80/80/80/80
Interface 50pin RGB,Parallel 24bit
Constrast ratio 1000:1
Operation Temp -40℃~90℃
Storage Temp. -30℃~85℃
Backlight White LED
Application automobile,car diagnostic instrument,electric motorcycle
