54 pin RGB Interface 3.5 Inch Tft Lcd Screen display 320X240 for electric bike

Specification parameters

Brand Hetech
P/N HC035IB50033-A88
Size 3.5"(IPS)
Display mode IPS,Transmissive,normally black
Resolution 320X240
Aspect ratio 4:3
Outline Dimension(mm) 76.9(W) x 63.9(H) x 3.26(D)
Active Area(mm) 70.08(W) x 52.56(H)
Brightness(cd/m²） 500cd/㎡
Viewing Angle(L/R/T/B) 80/80/80/80
Interface 54pin RGB
Constrast ratio 1000:1
Touch panel NA
Operation Temp -20℃~70℃
Storage Temp. -30℃~80℃
Backlight White LED
Application automobile,car diagnostic instrument,electric motorcycle
