HC070IK25035-B18V.CV01

Specification parameters

Brand HETECH
P/N HC070IK25035-B18V.CV01
Size 7"(IPS)
Display mode IPS,Transmissive,normally black
Resolution 1024X600
Aspect ratio 16:9
Outline Dimension(mm) 164.9(W) x100(H) x3.5(D)
Active Area(mm) 154.08 (W) × 85.92(H)
Brightness(cd/m²） 250cd/㎡
Viewing Angle(L/R/T/B) 80/80/80/80
Interface 40pin LVDS
Constrast ratio 500:1
Operation Temp -20℃~70℃
Storage Temp. -30℃~80℃
Backlight White LED
Application handheld terminals,testing machine,electric bicycle，office printer
