480*272 resolution 4.3 inch with RTP TFT LCD Module 250 nits with RGB interface(HC043TE30029-B03V.C)

Specification parameters

P/N HC043TE30029-B03V.C
Size 4.3"(TN)
Display type TN
Resolution 480*272
Aspect ratio 16:9
Contrast ratio 500:1
Outline Dimension(mm) 115.5(W)*80.00(H)*4.6(D)mm
Active Area(mm) 95.04(W)*53.856(H)mm
Brightness(cd/m²） 250cd/m2
Viewing Angle(L/R/T/B) 70/70/50/70
Interface 40PIN RGB
Operation Temp -20~70℃
Storge Temp -30~80℃
Application Telephone entry and access control systems, Point-of-care biochemistry analyzer
